Eaton Vickers 829AN00102A / DG4V-5-2AJ-M-U-H7-22 Hydraulic Directional Valve



Eaton Vickers by Danfoss 829AN00102A / DG4V-5-2AJ-M-U-H7-22 Hydraulic Solenoid Operated Directional Control Valve. NFPA D05 / NG10 mounting. With 24VDC ISO 4400 / DIN 43650 Electrical Connector. 4-way, 2-position, spring off set. Vickers/ Danfoss 2A Spool Configuration.

Valve Type: 4-way, 2-position directional control valve (solenoid operated, spring offset). Maximum Flow Rate: Up to 32 gpm (120 L/min). Maximum Operating Pressure: 4500 psi (315 bar) on P, A, and B ports.

Coil Voltage: 24V DC with an ISO 4400 / DIN 43650 electrical connection. Mounting Standard: CETOP 05 / NFPA D05 (NG10) subplate or manifold interface.
